Product details

Model and specification Capacity Seam consumption Seam pressure Cooling water flow rate Ice water flow rate Total power Outline dimensions Weight Pipe diameter(ф)
t/h kg/h bar t/h t/h kw l*w*h kg material steam medium
BR1-BS-XPJ-1SJ 1 40 2.5 1.5 3 2.2 1.6*1.4*1.8 690 32 DN25 32
BR1-BS-XPJ-2SJ 2 80 2.5 3.0 6 2.2 1.6*1.4*1.8 730 32 DN25 38
BR1-BS-XPJ-3SJ 3 120 2.5 4.5 9 4 1.8*1.6*2.2 900 38 DN25 38
BR1-BS-XPJ-4SJ 4 160 2.5 6.0 12 4 1.8*1.6*2.2 940 38 DN32 51
BR1-BS-XPJ-5SJ 5 200 2.5 7.5 15 5 1.8*1.6*2.2 980 38 DN32 51
BR1-BS-XPJ-6SJ 6 240 2.5 9.0 18 6 1.8*1.6*2.2 1020 51 DN25 51
BR1-BS-XPJ-8SJ 8 320 2.5 12.0 20 8 2.0*1.8*2.2 1100 51 DN25 63
BR1-BS-XPJ-10QJ 10 400 2.5 15.0 25 12 2.0*1.8*2.2 1180 51 DN32 63
BR1-BS-XPJ-15QJ 15 600 2.5 22.0 30 15 2.5*3.0*2.5 2080 63 DN32 63
BR1-BS-XPJ-20QJ 20 800 2.5 30.0 40 18 3.0*3.0*2.5 2280 63 DN40 76
BR1-BS-XPJ-30QJ 30 1200 2.5 45.0 50 20 3.0*3.0*2.5 2480 76 DN40 101
